Technical Specification
Sales Package (s) | Net contents | 1 N pumpset, 1 N instruction manual, 1 N warranty card, 1 N Strainer |
basic features | applications | Water
transfer for Apartments, bungalows, farm-houses, building construction,
gardening, fountains, overhead storage tanks, pressure booster systems,
hotels, hospitals, industrial water circulation | | high suction with self priming | up to 7.5 m | | low power consumption | Yes | | Maximum working pressure | 3.4 kg / cm² | | operating water temperature | Ambient temperature | | suitable for | Single Phase supply |
dimensions and weight | Cable length and Size | 0.3 m & 1.0 sq. mm |
dimensions weight accessories | packaging dimensions WxHxD (cm) | 27.3 cm x17.8 cm x 23.3 cm | | power supply cable | Yes |
motor features | direction of rotating | Anti-clockwise when viewed from driving end | | dynamically balanced rotor | Yes | | motor body | High-quality aluminium extruded body | | motor speed | 2900 Revolution per minute | | motor stator | Low Watt loss silicon steel lamination | | pipe size | 25 mm x 25 mm (2.5 cm x 2.5 cm) | | winding type | Copper winding |
power details | power | 0.75 kW (1.0 HP) | | rated frequency | 50 Hz | | voltage operating range | 180 V to 240 V |
pump features | pump casing | Cast iron | | impeller | Forged brass | | shaft | Carbon Steel Pump Shaft |
discharge in litre hour at various heights | 6 metre in L / h | 2700 L / h |
Sales Package (s) | Net contents | 1 N pumpset, 1 N instruction manual, 1 N warranty card, 1 N Strainer |
basic features | applications | Water
transfer for Apartments, bungalows, farm-houses, building construction,
gardening, fountains, overhead storage tanks, pressure booster systems,
hotels, hospitals, industrial water circulation | | high suction with self priming | up to 7.5 m | | low power consumption | Yes | | Maximum working pressure | 3.4 kg / cm² | | operating water temperature | Ambient temperature | | suitable for | Single Phase supply |
dimensions and weight | Cable length and Size | 0.3 m & 1.0 sq. mm |
dimensions weight accessories | packaging dimensions WxHxD (cm) | 27.3 cm x17.8 cm x 23.3 cm | | power supply cable | Yes |
motor features | direction of rotating | Anti-clockwise when viewed from driving end | | dynamically balanced rotor | Yes | | motor body | High-quality aluminium extruded body | | motor speed | 2900 Revolution per minute | | motor stator | Low Watt loss silicon steel lamination | | pipe size | 25 mm x 25 mm (2.5 cm x 2.5 cm) | | winding type | Copper winding |
power details | power | 0.75 kW (1.0 HP) | | rated frequency | 50 Hz | | voltage operating range | 180 V to 240 V |
pump features | pump casing | Cast iron | | impeller | Forged brass | | shaft | Carbon Steel Pump Shaft |
discharge in litre hour at various heights | 6 metre in L / h | 2700 L / h |
|
