Technical Specification
motor type | motor insulation class | Class F |
Sales Package (s) | Net contents | 1 N pump set, 1 N power cord of 1 m length, 1 N instruction manual, 1 N warranty card |
safety features | in built thermal overload protector | Yes |
basic features | applications | Apartments,
bungalows, farm-houses, building construction, gardening, fountains,
overhead storage tanks, pressure booster systems, hotels, hospitals,
industrial water circulation | | high suction with self priming | up to 8 m | | low power consumption | Yes | | Maximum working pressure | 3.4 kg / cm² | | operating water temperature | up to 65 °C | | suitable for | Single Phase supply |
dimensions weight | depth | 260 mm | | height | 242 mm | | weight | 11.5 kg | | width | 169 mm |
accessories motor features | direction of rotating | Anti-clockwise when viewed from driving end | | dynamically balanced rotor | Yes | | motor body | High-quality aluminium die casting | | motor speed | 2900 Revolution per minute | | motor stator | Low Watt loss silicon steel lamination | | pipe size | 25 mm x 25 mm (2.5 cm x 2.5 cm) | | winding type | Copper winding |
packaging measurements | Packaging Dimensions (cm) | 33.2 cm x 26 cm x 30.5 cm |
power details | high quality mechanical seal | Yes | | power | 0.37 kW (0.5 HP) | | rated frequency | 50 Hz | | voltage operating range | 180 V to 240 V | | rated input current | 2.4 Ampere |
pump features | ss vs teflon carbon thrust bearing set ltb bush on both side | Yes | | pump casing | Graded Cast Iron | | impeller | Forged brass | | shaft | Stainless Steel (SS-410) |
warranty | Net contents | 1 N pump set, 1 N power cord of 1 m length, 1 N instruction manual, 1 N warranty card | | guarantee | 2 Year |
discharge in litre hour at various heights | 18 metre in L / h | 1870 L / h | | 6 metre in L / h | 2700 L / h | | 15 metre in L / h | 2150 L / h | | 12 metre in L / h | 2350 L / h | | 9 metre in L / h | 2550 L / h | | 21 metre in L / h | 1570 L / h | | 24 metre in L / h | 1360 L / h | | 27 metre in L / h | 1080 L / h | | 33 metre in L / h | 610 L / h | | 34 metre in L / h | 490 L / h | | 30 metre in L / h | 900 L / h |
|
