Technical Specification
motor type | motor insulation class | Class B |
Sales Package (s) | Net contents | 1 N pump set, 1 N power cord of 5 m length, 1 N instruction manual, 1 N warranty card |
basic features | applications | Apartments,
bungalows, farm-houses, building construction, gardening, fountains,
overhead storage tanks, pressure booster systems, hotels, hospitals,
industrial water circulation | | low power consumption | Yes | | Maximum working pressure | 7.2 kg / cm² | | operating water temperature | up to 65 °C | | suitable for | Single Phase supply |
dimensions weight accessories | packaging dimensions WxHxD (cm) | 11.5 cm x 21.8 cm x 63.5 cm | | power supply cable | Yes |
motor features | direction of rotating | Anti-clockwise when viewed from driving end | | dynamically balanced rotor | Yes | | motor body | SS / Special grade Cast Iron | | motor speed | 2900 Revolution per minute | | motor stator | High grade CRNO stampings | | pipe size | 32 mm | | winding type | PVC insulated Copper winding |
power details | power | 0.75 kW (1.0 HP) | | rated frequency | 50 Hz | | voltage operating range | 180 V to 240 V | | rated input current | 5.5 Ampere |
pump features | ss vs teflon carbon thrust bearing set ltb bush on both side | Yes | | pump casing | Stainless steel tube | | impeller | Noryl | | shaft | Stainless Steel (SS-410) |
warranty | Net contents | 1 N pump set, 1 N power cord of 5 m length, 1 N instruction manual, 1 N warranty card | | guarantee | 1 Year |
discharge in litre hour at various heights | 8 metre in L / minute | 5400 - 1740 |
|
